Romex Wire 12-2 W/gr 50‘

PRODUCT OVERVIEW

Inner conductors are type THHN, rated 90 degrees Celsius, 600 volt. Solid strands. Outer jacket is PVC, rated at 75 degrees Celsius. Amp rating of the product is limited to that for 60 degrees Celsius rated conductors per the National Electric Code Article 336. Dwellings not exceeding 3 floors above grade. Exposed or concealed wiring. May be fished through walls, ceilings, and masonry blocks. Use for new wiring or replacement wiring. Only for use in normally dry locations. UL Listed. /2 = 2 insulated wires with bare ground. /3 = 3 insulated wires with bare ground.

Product Details

Conductor Insulation	PVC
Conductor Material	Copper
Current Rating	30 A
Length	50 ft
Number of Conductors	2
Operating Temperature	90 deg C
Package Type	Box
Sheath Color	Yellow
Sheath Material	Nylon
Stranded/Solid	Solid
Strands per Conductor	1
Type	NM-B
Voltage Rating	600 V
Wire Size	12 AWG
